Multi-turn rotary potentiometer with protection resistor 3590S 100K ohm with adjustable resistance

Independent linearity accuracy makes this module a good choice for your electronics project. High precision combined with modern and user-friendly design makes this product easy to use.

Special Features:

Resistance: 100K ΩWindings: 10 windingsShaft diameter: 6.3mm, mounting hole: 10mmResistance tolerance: ±5%, independent linearity accuracy: ±0.25%.Lifetime: 1,000,000 revolutions

Technical data

Revolutions 10

Lifetime 1.000.000 revolutions

Power 2W

Resistance value 100K Ohm

Resistor tolerance ± 5%

Linearity ± 0,25%

Shaft diameter 6mm/0.24"

Thread diameter 9mm/0.35"

Total length 40mm/1.6"

Lifetime load 1000 hours

Mechanical angle 3600 ° ± 10 °

Operating temperature range -55 ° - 125 °

Size (without hearing wave) 22x1 9mm/0.9 "x 0.7"(DxH)

Possible risks:

The potentiometer has an extreme durability. However, it should not be stored in rooms with extremely hot temperatures.
