Sparkfun FLiR Lepton Breakout Board V2

The FLIR Lepton® Thermal Camera Breakout Board is a versatile and user-friendly evaluation board designed to connect the FLIR Lepton camera module to platforms like Raspberry Pi or custom hardware swiftly. This compact board, measuring only 29.5 mm x 29.0 mm, comes with onboard power supplies that are generated from a 3 – 5.5V input voltage, and a master clock. You can bypass local power supplies, the master clock, and the power-up sequence components using a jumper. It's important to note that the Breakout Board V2 does not include a FLIR Lepton Module. The FLIR Lepton® Thermal Camera Breakout Board is compatible with all FLIR Lepton modules, making it a versatile tool for various applications. Whether you're a hobbyist looking to experiment with thermal imaging or a professional requiring a reliable thermal imaging solution, this breakout board can adapt to your needs.One of the key benefits of the FLIR Lepton® Thermal Camera Breakout Board is its operating temperature range of 0°C to 55°C. This wide range ensures the board's reliable performance under various environmental conditions. Additionally, its compact size offers space-saving benefits, making it ideal for projects where space is at a premium.Unique to this board is its flexibility in power supply options. You can choose to use the onboard power supplies or bypass them using a jumper. This feature allows for greater customization based on the specific requirements of your project.For more detailed information, you can refer to the datasheet, schematic, and breakout drawing provided by Sparkfun.
