Quad Buck Regulator Integrated Power Solution

The ADP5054 combines four high performance buck regulators in a 48-lead LFCSP package that meets demanding performance and board space requirements. The device enables direct connection to high input voltages of up to 15.5 V with no preregulators.

Channel 1 and Channel 2 integrate high-side power metal-oxide semiconductor field effect transistors (MOSFETs) and low-side MOSFET drivers. External NFETs can be used in low-side power devices to achieve an efficiency optimized solution and to deliver a programmable output current of 2 A, 4 A, or 6 A. Combining Channel 1 and Channel 2 in a parallel configuration provides a single output with up to 12 A of current.

Channel 3 and Channel 4 integrate both high-side and low-side MOSFETs to deliver an output current of 2.5 A. Combining Channel 3 and Channel 4 in a parallel configuration can provide a single output with up to 5 A of current.

The switching frequency of the ADP5054 can be programmed or synchronized to an external clock from 250 kHz to 2 MHz, and an individual ½× frequency configuration is available for each channel.

The ADP5054 contains an individual precision enable pin on each channel for easy power-up sequencing. The internal low 1/f noise reference is implemented in the ADP5054 for noise sensitive applications.

Applications

* FPGA and processor applications

* Small cell base stations

* Security and surveillance

* Medical applications

* Wide input voltage range: 4.5 V to 15.5 V

* ±1.5% output accuracy over full temperature range

* 250 kHz to 2 MHz adjustable switching frequency with individual ½× frequency option

* Power regulation

* Channel 1 and Channel 2

* Programmable 2 A/4 A/6 A sync buck regulators with low-side FET drivers

* Channel 3 and Channel 4: 2.5 A sync buck regulators

* Flexible parallel operation

* Single 12 A output (Channel 1 and Channel 2 in parallel)

* Single 5 A output (Channel 3 and Channel 4 in parallel)
