    BTT3050EJ

    The BTT3050EJ is a 50 mΩ single channel Smart Low-Side Power Switch within a PG-TDSO-8 exposed package providing embedded protective functions. The power transistor is built by an N-channel vertical power MOSFET. The BTT3050EJ is monolithically integrated. The BTT3050EJ is automotive qualified and is optimized for 24 V automotive applications.
    Producent:
    Infineon
    Rozmiar:
    1592 kB
    Stron:
    47
  2. Podgląd PDFa
    Do dokumentacji »

    IPTC012N06NM5

    OptiMOS™ 5 power MOSFET 60 V in TOLT for excellent thermal performance IPTC012N06NM5 is part of the OptiMOS™ 5 power MOSFET in TOLT family: the TO-Leaded top-side cooling package for superior thermal performance. This innovative package combined with the key features of OptiMOS™ 5 technology allows best-in-class products in 60 V as well as high current rating >300 A for high-power density designs. With top-side cooling setup, the drain is exposed at the surface of the package enabling 95 percent of the
    Producent:
    Infineon
    Rozmiar:
    1406 kB
    Stron:
    11
  3. Podgląd PDFa
    Do dokumentacji »

    IPTC007N06NM5

    OptiMOS™ 5 power MOSFET 60 V in TOLT for excellent thermal performance IPTC007N06NM5 is part of the OptiMOS™ 5 power MOSFET in TOLT family: the TO-Leaded top-side cooling package for superior thermal performance. This innovative package combined with the key features of OptiMOS™ 5 technology allows best-in-class products in 60 V as well as high current rating >400 A for high-power density designs. With top-side cooling setup, the drain is exposed at the surface of the package enabling 95 percent of the
    Producent:
    Infineon
    Rozmiar:
    1385 kB
    Stron:
    11
  4. Podgląd PDFa
    Do dokumentacji »

    BTM9011EP

    MOTIX™ BTM9011EP is a fully integrated H-bridge motor driver with SPI interface & adjustable slew rate at two levels for an improved EMC performance. The MOTIX™ BTM9011EP full-bridge IC provides a cost optimized solution for easy design in. The supply voltage of the device is at 7 V to 18 V. It suits automotive applications with limitation of minimum 10 A and covers PWM frequency of up to 20 kHz. BTM9011EP stands out due to its small (4,9 x 6,0mm) package with exposed pad leading to enhanced thermal co
    Producent:
    Infineon
    Rozmiar:
    1298 kB
    Stron:
    46
  5. Podgląd PDFa
    Do dokumentacji »

    BTH6200-1ENA

    RDS(on) @ Tj = 25°C: 200 mΩ | 1 channel | Vs (extended) = 60V | PRO-SIL™ ISO 26262-ready The BTH6200-1ENA, as part of the PROFET™ + 48V family, features 1 channel with proportional analog current sense. This 200 mΩ device is suitable for a 48 V board net. It comes in a small TDSO-8 exposed pad package offering protection and diagnostic functions.
    Producent:
    Infineon
    Rozmiar:
    1151 kB
    Stron:
    41
  6. Podgląd PDFa
    Do dokumentacji »

    AB1805-T3

    Real Time Clock (RTC) IC Clock/Calendar 256B I²C, 2-Wire Serial 16VFQFN Exposed Pad
    Producent:
    Abracon
    Rozmiar:
    1144 kB
    Stron:
    97
  7. Podgląd PDFa
    Do dokumentacji »

    AB0805-T3

    Real Time Clock (RTC) IC Clock/Calendar 256B I²C, 2-Wire Serial 16VFQFN Exposed Pad
    Producent:
    Abracon
    Rozmiar:
    1058 kB
    Stron:
    87
  8. Podgląd PDFa
    Do dokumentacji »

    BTM9021EP

    MOTIX™ BTM9021EP is a fully integrated H-bridge motor driver with SPI interface & adjustable slew rate at two levels for an improved EMC performance. The MOTIX™ BTM9021EP full-bridge IC provides a cost optimized solution for easy design in. The supply voltage of the device is at 7 V to 18 V. It suits automotive applications with limitation of minimum 20 A and covers PWM frequency of up to 20 kHz. BTM9021EP stands out due to its small (4,9 x 6,0mm) package with exposed pad leading to enhanced thermal co
    Producent:
    Infineon
    Rozmiar:
    1014 kB
    Stron:
    47
  9. Podgląd PDFa
    Do dokumentacji »

    BTH6200-4ESA

    RDS(on) @ Tj = 25°C: 200 mΩ | 4 channels | Vs (extended) = 60V | PRO-SIL™ ISO 26262-ready The BTH6200-4ESA, as part of the PROFET™ + 48V family, features 4 channels with proportional analog current sense. This 200 mΩ quad-channel device is suitable for a 48 V board net. It comes in a TSDSO-24 exposed pad package offering protection and diagnostic functions.
    Producent:
    Infineon
    Rozmiar:
    955 kB
    Stron:
    41
  10. Podgląd PDFa
    Do dokumentacji »

    BTH6100-2EPA

    RDS(on) @ Tj = 25°C: 100 mΩ | 2 channels | Vs (extended) = 60V | PRO-SIL™ ISO 26262-ready The BTH6100-2EPA, as part of the PROFET™ + 48V family, features 2 channels with proportional analog current sense. This 100 mΩ dual-channel device is suitable for a 48 V board net. It comes in a small TSDSO-14 exposed pad package and is footprint compatible with family members, offering protection and diagnostic functions.
    Producent:
    Infineon
    Rozmiar:
    930 kB
    Stron:
    41
  11. Podgląd PDFa
    Do dokumentacji »

    BTH6070-2EPV

    RDS(on) @ Tj = 25°C: 60 mΩ | 2 channels with 2 current sense pins | fast switching | Vs (extended) = 60V | PRO-SIL™ ISO 26262-ready The BTH6070-2EPV, as part of the PROFET™ + 48 family, features 2 channels with 2 analog current sense. This fast switching 60 mΩ dual-channel device is suitable for a 48 V board net. It comes in a small TSDSO-14 exposed pad package and is footprint compatible with family members, offering protection and diagnostic functions.
    Producent:
    Infineon
    Rozmiar:
    929 kB
    Stron:
    41
