    TDA38840

    OptiMOS™ integrated point-of-load 40 A single output high efficiency buck regulator The TDA38840 OptiMOS™ IPOL 40 A is an easy-to-use, fully integrated DC-DC buck regulator with patented fast Constant-On-Time (COT) control scheme. It simplifies the design effort, while enabling an enhanced transient response and improved Vout regulation. The onboard PWM controller and OptiMOS™ 5 MOSFETs with integrated bootstrap diode make the TDA38840 a small footprint, high efficiency solution for various point-of-load a
    Producent:
    Infineon
    Rozmiar:
    3338 kB
    Stron:
    53
  2. Podgląd PDFa
    Do dokumentacji »

    TDA38540

    OptiMOS™ IPOL 40 A single-voltage stackable synchronous buck regulator TDA38540 40 A DC-DC buck regulator features an onboard PWM controller and OptiMOS™ 5 FETs resulting in a very efficient, easy-to-use, compact VR solution. It enables stacking (up to 4) and can optionally sync to an external clock signal. TDA38540 provides extensive protection features such as pre-bias start up, UVP, OVP, etc. to give required system-level security in the event of fault conditions.
    Producent:
    Infineon
    Rozmiar:
    3044 kB
    Stron:
    54
  3. Podgląd PDFa
    Do dokumentacji »

    TDA38820

    OptiMOS™ IPOL 20 A Single Output High Efficiency Buck Regulator The TDA38820 OptiMOS™ IPOL is an easy-to-use, fully integrated DC-DC buck regulator. It uses a fast Constant-On-Time (COT) control scheme, which simplifies the design effort and achieves fast control response. The onboard PWM controller and OptiMOS™ 5 MOSFETs with integrated bootstrap diode make the TDA38820 a small footprint solution, providing high-efficiency power delivery.
    Producent:
    Infineon
    Rozmiar:
    2571 kB
    Stron:
    50
  4. Podgląd PDFa
    Do dokumentacji »

    IR3888BMTRPBF

    OptiMOS™ integrated point-of-load 16 A single output high efficiency buck regulator The IR3888B OptiMOS™ IPOL 16 A is an easy-to-use, fully integrated DC-DC buck regulator with patented fast Constant-On-Time (COT) control scheme. It simplifies the design effort, while enable an enhanced transient response and improved Vout regulation. The onboard PWM controller and OptiMOS™ 5 MOSFETs with integrated bootstrap diode make the IR3888B a small footprint, high efficiency solution for various point-of-load appli
    Producent:
    Infineon
    Rozmiar:
    2074 kB
    Stron:
    43
  5. Podgląd PDFa
    Do dokumentacji »

    MCP3421

    18-Bit ADC with I2C Interface and Onboard Reference
    Producent:
    Microchip
    Rozmiar:
    723 kB
    Stron:
    42
  6. Podgląd PDFa
    Do dokumentacji »

    CYW20829B0-P4TAI100

    The CYW20829B0-P4TAI100 is a fully integrated Bluetooth® LE wireless module. The CYW20829B0-P4TAI100 includes an onboard crystal oscillator, passive components, flash memory, and the CYW20829 - the Bluetooth® LE 5.4 MCU with Industry’s best range, ARM® Cortex® -M33 dedicated for applications and CAN FD. The CYW20829B0-P4TAI100 includes an integrated trace antenna.
    Producent:
    Infineon
    Rozmiar:
    680 kB
    Stron:
    34
  7. Podgląd PDFa
    Do dokumentacji »

    TDM22545T

    OptiMOS™ Dual-phase TLVR power module 140 A TDM22545T OptiMOS™ Dual-phase TLVR power module co-packages two smart power stages and two TLVR power inductors to implement two independent synchronous buck converters into a small 10x9x4.8 mm package. The TLVR inductor reduces the size of the onboard decoupling capacitors and provides much faster transient response during large load current transitions.
    Producent:
    Infineon
    Rozmiar:
    361 kB
    Stron:
    7
  8. Podgląd PDFa
    Do dokumentacji »

    AD7545

    CMOS 12-Bit Buffered Multiplying DAC With Onboard Data Latches
    Producent:
    Analog Devices
    Rozmiar:
    196 kB
    Stron:
    8
