  1. Podgląd PDFa
    Do dokumentacji »

    KP305

    XENSIV™ - KP305 pressure sensor IC for side crash detection and pedestrian protection The Infineon XENSIV KP305 is a pressure sensor for side crash detection in passenger cars and other collision detection systems. It provides an output proportional to the pressure change inside a crash-sensitive air volume, offering relative pressure as a digital Manchester encoded output signal for autonomous operation without additional logic ICs.
    Producent:
    Infineon
    Rozmiar:
    2360 kB
    Stron:
    43
  2. Podgląd PDFa
    Do dokumentacji »

    KP300

    XENSIV™ - KP300 pressure sensor IC for side crash detection and pedestrian protection The Infineon XENSIV KP300 is a pressure sensor used for side crash detection in passenger cars. It is assembled in a door module within the car's side door and provides an output proportional to the pressure change inside the sensitive air volume (∆p/p0). The relative pressure is provided as a digital Manchester encoded output signal, enabling autonomous sensor operation without additional logic ICs in the pressure satell
    Producent:
    Infineon
    Rozmiar:
    2324 kB
    Stron:
    38
  3. Podgląd PDFa
    Do dokumentacji »

    KP405

    XENSIV™ - KP405 pressure sensor, ISO 26262-compliant for side crash, pedestrian impact and front crash detection in small DFN package The KP400 is a monolithically integrated pressure sensor with a programmable PSI5 interface, designed for passive safety vehicle systems. It provides fast reaction times and helps fulfill current and future safety tests. Used in side airbag and pedestrian protection applications, it offers a signal pulse proportional to pressure changes, with an amplitude independent of ambi
    Producent:
    Infineon
    Rozmiar:
    1671 kB
    Stron:
    40
  4. Podgląd PDFa
    Do dokumentacji »

    KP400

    XENSIV™ - KP400 pressure sensor, ISO 26262-compliant for side crash, pedestrian impact and front crash detection in small DFN package The KP400 is a monolithically integrated pressure sensor with a programmable PSI5 interface, designed for passive safety vehicle systems. It provides fast reaction times and helps fulfill existing and future safety tests. Used in side airbag applications, the KP400 offers a signal pulse proportional to pressure change, with an amplitude independent of ambient pressure. It's
    Producent:
    Infineon
    Rozmiar:
    1620 kB
    Stron:
    37
  5. Podgląd PDFa
    Do dokumentacji »

    BTH6200-1ENA

    RDS(on) @ Tj = 25°C: 200 mΩ | 1 channel | Vs (extended) = 60V | PRO-SIL™ ISO 26262-ready The BTH6200-1ENA, as part of the PROFET™ + 48V family, features 1 channel with proportional analog current sense. This 200 mΩ device is suitable for a 48 V board net. It comes in a small TDSO-8 exposed pad package offering protection and diagnostic functions.
    Producent:
    Infineon
    Rozmiar:
    1151 kB
    Stron:
    41
  6. Podgląd PDFa
    Do dokumentacji »

    BTH6200-4ESA

    RDS(on) @ Tj = 25°C: 200 mΩ | 4 channels | Vs (extended) = 60V | PRO-SIL™ ISO 26262-ready The BTH6200-4ESA, as part of the PROFET™ + 48V family, features 4 channels with proportional analog current sense. This 200 mΩ quad-channel device is suitable for a 48 V board net. It comes in a TSDSO-24 exposed pad package offering protection and diagnostic functions.
    Producent:
    Infineon
    Rozmiar:
    955 kB
    Stron:
    41
  7. Podgląd PDFa
    Do dokumentacji »

    BTH6100-2EPA

    RDS(on) @ Tj = 25°C: 100 mΩ | 2 channels | Vs (extended) = 60V | PRO-SIL™ ISO 26262-ready The BTH6100-2EPA, as part of the PROFET™ + 48V family, features 2 channels with proportional analog current sense. This 100 mΩ dual-channel device is suitable for a 48 V board net. It comes in a small TSDSO-14 exposed pad package and is footprint compatible with family members, offering protection and diagnostic functions.
    Producent:
    Infineon
    Rozmiar:
    930 kB
    Stron:
    41
  8. Podgląd PDFa
    Do dokumentacji »

    TLE4973-RE35D5-S0001

    XENSIV™ - TLE4973-RE35D5-S0001 high accuracy coreless current sensor with digital control and diagnostic interface in a leaded TDSO-16 package TLE4973-RE35D5-S0001 provides analog output proportional to the magnetic field measured and over current detection output. Digital control and diagnostic interface provide temp. and safety status readout, read/write progr. access to internal E2PROM, control of diagnosis mode. Infineon’s Hall technology enables accurate and highly linear measures. Its measurement ran
    Producent:
    Infineon
    Rozmiar:
    925 kB
    Stron:
    33
  9. Podgląd PDFa
    Do dokumentacji »

    TLE4973-RE35D5-S0010

    XENSIV™ - TLE4973-RE35D5-S0010 high accuracy coreless current sensor with digital control and diagnostic interface in a leaded TDSO-16 package TLE4973-RE35D5-S0010 provides analog output proportional to the magnetic field measured and over current detection output. Digital control and diagnostic interface provide temp. and safety status readout, read/write progr. access to internal E2PROM, control of diagnosis mode. Infineon’s Hall technology enables accurate and highly linear measures. Its measurement ran
    Producent:
    Infineon
    Rozmiar:
    879 kB
    Stron:
    30
  10. Podgląd PDFa
    Do dokumentacji »

    10LPCV2475 CRYDOM

    SCR proportional controller , 0-10V DC, 0,15-75A RMS, 20-300 V RMS, AC
    Producent:
    Meditronik
    Rozmiar:
    195 kB
    Stron:
    5
  11. Podgląd PDFa
    Do dokumentacji »

    RPC4840 CRYDOM

    proportional controller. Proportional controller - 0-1 potentiometer ; 0,9-40 Amps RMS; 400-480 V RMS Switching vol tage AC
    Producent:
    Meditronik
    Rozmiar:
    71 kB
    Stron:
    3
  12. Podgląd PDFa
    Do dokumentacji »

    10PCV2475 CRYDOM

    Proportional controller; 2-10V DC; load voltage 100-240 V switching voltage type - AC
    Producent:
    Meditronik
    Rozmiar:
    43 kB
    Stron:
    2
