  1. Podgląd PDFa
    Do dokumentacji »

    PW70II/AII/IP65-2x5K-70deg

    Precision Potentiometer Typ: PW70IIAII-IP65 1709Z03-360.002 in cast casing of model AII with 2 cable connections IP code IP65 driving shaft 6 mm Ý length from surface 16mm potentiometer PW70II (1700Z04-104.001) with 2 windings on a common winding form with 1 wiper each winding angle each: 70°, stops with slipping clutch value of resistance: 2 x 5 kU ± 2% tariff # 85 33 31 000 article weight: 0,550 KG
    Producent:
    Meditronik
    Rozmiar:
    840 kB
    Stron:
    2
  2. Podgląd PDFa
    Do dokumentacji »

    1700Z04-096.059

    Potencjometr z modelu PW70/A/IP40-350-5K-1708Z03-096.008 i z takiego samego tylko IP65 zamiast IP40 PW70/A/IP65 350 5K 1708z03-352.078 ( z potencjometrem 1708z04-096.059) 1700Z04-096.059 Precision Potentiometer PW70-RK winding angle 350°, stops resistance 5 kU ± 1% / 350° shaft 6 mm Ý, LF 1 = 29 according to 0233 BPW-00:01 with incorporated slipping clutch cap with bore hole and cover i. e. cover according to 1700Z04-00:2602 and cover according to 1700Z04-00:2701 Uwaga: zdjęcie podobnego
    Producent:
    Meditronik
    Rozmiar:
    469 kB
    Stron:
    1
  3. Podgląd PDFa
    Do dokumentacji »

    1708Z03-096.018

    PW70A Precision Potentiometer in cast iron case to IP40. Potentiometer is 8.57k Ohms +-1% across the 60 Degree movement, without gears and includes a slipping clutch for mechanical protection. 125mm x 75mm x 60mm overall. Shaft is 6mm x 16mm Fixing flange has 4 x 6mm dia smooth holes on 88mm pcd. Used on FAS Packaging Machinery and any high performace dancer bar or dancing roller applications. Other resistance values are available on request. Customs Tariff code: 85 33 31 000 Potencjometr 1700Z04-096.038 Pa
