    1708Z03-065.009

    Potentiometer in Cast Iron IP40 Case - 350 Degree Movement x 10k Ohms - PW70d/A 1708Z03-065.009 PW70d/A Precision Potentiometer in cast iron case to IP40 enclosure rating. Potentiometer is 10k Ohms +-1% across 350 Degree movement (within 360 degree mechanical rotation). 125mm x 75mm x 60mm overall. Shaft is 6mm x 16mm Fixing flange has 4 x 6mm dia smooth holes on 88mm pcd. Used for Thruster Position sensing, dancer bar/dancing roller and any high performace/high reliability applications.
    Producent:
    Meditronik
    Rozmiar:
    930 kB
    Stron:
    1
  2. Podgląd PDFa
    Do dokumentacji »

    1700Z04-065.039

    W70DPrecision Potentiometer in cast iron case to IP40 enclosure rating. Potentiometer is 2k Ohms +-1% across 350 Degree movement (within 360 degree mechanical rotation) ( Brak - Centre tapping, Wiper pressure 15-18 p. ???? ) Size Depth 27.5mm excluding the 24mm Shaft is 6mm x 24mm (shaft # 0001W01-00:0108) Fixing 2 X M4 (5mm deep) Used for Thruster Position sensing, dancer bar/dancing roller and any high performace/high reliability applications. Other resistance values are available on request. Manufact
    Producent:
    Meditronik
    Rozmiar:
    142 kB
    Stron:
    1
