UPO3152E Digital Storage 2 Channel Analog Oscilloscope 150MHz Uni-T

The UPO3152E digital phosphor oscilloscope is a multifunctional and high-performanceoscilloscope based on UNI-T's original Ultra Phosphor 2.0 technology. It realizes the combinationof ease of use, excellent technical indicators and many functional features. It can help users complete the measurement work faster. It is an oscilloscope designed for general design / debugging / testing needs in many fields, such as communication, semiconductor, computer, instrumentation, industrial electronics, consumer electronics, automotive electronics, on-site maintenance, R & D / education, etc. Fast Acquire technology can accurately capture abnormal events such as video, jitter, noise and low wave signals.

* Bandwidth: 150MHz * Real time sample rate: 2.5GSa/s * Waveform capture rate: 200,000 wfms/s * 2 channels * Maximum memory depth: 70Mpts * 8 inch screen * Rich measurement functions * XY mode * Ultra high capture rate * 256-level grayscale display * Channel split screen function Multi-Scopes 2.0 * Memory depth 70Mpts per channel * Rich trigger function * Full memory hardware decoding * Area trigger * Bode plot * LA Logic Analyzer
