  1. Podgląd PDFa
    Do dokumentacji »

    1EDR3147HQE

    5.7 kV (rms) single-channel gate driver IC with AEC-Q100 qualification, reinforced isolation, 6.5 A output current, 15 V UVLO EiceDRIVER™ Compact 2300 V single-channel isolated gate driver with +/-6.5 A typical peak output current in an 8-pin DSO wide body package for GaN HEMTs, IGBTs, MOSFETs and SiC MOSFETs. Qualified according to AEC-Q100. Offers Separate Outputs, enabling separate turn-on and turn-off gate resistors without the need for a bypass Schottky diode.
    Producent:
    Infineon
    Rozmiar:
    2462 kB
    Stron:
    37
  2. Podgląd PDFa
    Do dokumentacji »

    1ED3141MC12H

    5.7 kV single-channel gate driver IC with reinforced isolation, 6.5 A output current, separate outputs, 11 V UVLO
    Producent:
    Infineon
    Rozmiar:
    2098 kB
    Stron:
    51
  3. Podgląd PDFa
    Do dokumentacji »

    1EDI60N12AF

    MOSFET DRVR 6A 1-OUT Hi Side Inv/Non-Inv 8-Pin DSO T/R
    Producent:
    Infineon
    Rozmiar:
    1975 kB
    Stron:
    22
  4. Podgląd PDFa
    Do dokumentacji »

    1EDI3050AS

    The EiceDRIVER™ 1EDI3050AS is an automotive qualified single-channel high-voltage gate driver optimized for IGBT and SiC power technologies. The EiceDRIVER™ 1EDI3051AS is galvanically isolated using Infineon’s coreless transformer technology. Comprehensive safety features and ISO 26262-compliance enable system level ASIL D classification, while accompanying safety documents ease FMEDA analysis. Full configurability via SPI enables platform development. The integrated high accuracy flyback controller can op
    Producent:
    Infineon
    Rozmiar:
    1739 kB
    Stron:
    150
  5. Podgląd PDFa
    Do dokumentacji »

    1EDI3051AS

    The EiceDRIVER™ 1EDI3051AS is an automotive qualified single-channel high-voltage gate driver optimized for IGBT and SiC power technologies. The EiceDRIVER™1EDI3051AS uses robust Infineon Coreless Transformer Technology to provide bi-directional signal transfer across the galvanic isolation barrier. Comprehensive safety features and ISO 26262-compliance enable ASIL D classification on system level. Accompanying safety documents ease and speed-up FMEDA analysis in the application.
    Producent:
    Infineon
    Rozmiar:
    1730 kB
    Stron:
    148
  6. Podgląd PDFa
    Do dokumentacji »

    1EDN7146U

    200 V high-side TDI gate driver IC for GaN SG HEMTs and MOSFETs The 1EDN7146U is a single-channel gate-driver IC optimized for driving Infineon CoolGaN™ Schottky gate (SG) HEMTs, as well as other GaN SG HEMTs and Si MOSFETs This gate driver includes several key features that enable a high-performance system design with fast-switching transistors, including Truly Differential Input (TDI), 0.5 A peak source and sink current, active Miller clamp, and bootstrap voltage clamp.
    Producent:
    Infineon
    Rozmiar:
    1576 kB
    Stron:
    34
  7. Podgląd PDFa
    Do dokumentacji »

    1EDI3025AS

    The EiceDRIVER™ 1EDI3025AS is an automotive qualified single-channel high-voltage gate driver optimized for IGBT technologies. The EiceDRIVER™ gate driver 1EDI3025AS is a high-voltage IGBT driver designed for automotive applications, with 8 kV galvanic insulation using coreless transformer (CT) technology. It features a powerful output stage of up to 20 A peak current for high power switches. It has a split output stage enabling different slew rates for switching on and off via separate gate resistors and
    Producent:
    Infineon
    Rozmiar:
    1215 kB
    Stron:
    76
  8. Podgląd PDFa
    Do dokumentacji »

    1EDI3035AS

    The EiceDRIVER™ 1EDI3035AS is an automotive qualified single-channel high-voltage gate driver optimized for SiC MOSFET. The EiceDRIVER™ gate driver 1EDI3035AS is a high-voltage SiC MOSFET driver for automotive applications, featuring 8 kV galvanic insulation with coreless transformer (CT) technology. The IC supports up to 1200 V SiC-MOSFETs and is ideally suitable to drive the IGBT + SiC HybridPACK™ Drive G2 Fusion module. The device features a powerful output stage of up to 20 A peak current required for
    Producent:
    Infineon
    Rozmiar:
    1193 kB
    Stron:
    76
  9. Podgląd PDFa
    Do dokumentacji »

    1EDI3026AS

    The EiceDRIVER™ 1EDI3026AS is an automotive qualified single-channel high-voltage gate driver optimized for IGBT technologies. The EiceDRIVER™ gate driver 1EDI3026AS is a high-voltage IGBT driver for automotive applications, offering 8 kV galvanic insulation with coreless transformer (CT) technology. It provides a powerful output stage with up to 20 A peak current for high power switches. It features a split output stage for different slew rates during switching on and off, achieved by separate gate resist
    Producent:
    Infineon
    Rozmiar:
    1190 kB
    Stron:
    76
  10. Podgląd PDFa
    Do dokumentacji »

    1EDI3028AS

    The EiceDRIVER™ 1EDI3028AS is an automotive qualified single-channel high-voltage driver optimized for IGBT technologies. The EiceDRIVER™ gate driver 1EDI3028AS is a high-voltage IGBT driver for automotive applications, providing 8 kV galvanic insulation with coreless transformer (CT) technology. It offers a powerful output stage with up to 15 A peak current for high power switches. It features a split output stage for different slew rates during switching on and off, achieved by separate gate resistors, a
    Producent:
    Infineon
    Rozmiar:
    1167 kB
    Stron:
    72
  11. Podgląd PDFa
    Do dokumentacji »

    1EDN9550B

    1-channel non-isolated gate-driver IC family with truly differential inputs The 1EDN8550B is a non-isolated gate-driver IC and available in a small SOT-23 package. It has truly differential inputs enabling cost-effective solutions with exceptional power density in:Boost-PFC with Kelvin-source MOSFETsSynchronous rectification stagesDesigns with long distance between control IC and gate-driver ICBuck-boost convertersLow- and medium-voltage half-bridgesHigh density 48V to 12V intermediate bus converter
    Producent:
    Infineon
    Rozmiar:
    1166 kB
    Stron:
    32
  12. Podgląd PDFa
    Do dokumentacji »

    1EDI3038AS

    The EiceDRIVER™ 1EDI3038AS is an automotive qualified single-channel high-voltage gate driver optimized for SiC MOSFET. The EiceDRIVER™ gate driver 1EDI3038AS is a high-voltage SiC MOSFET driver for automotive applications, offering 8 kV galvanic insulation with coreless transformer (CT) technology. It provides a powerful output stage with up to 15 A peak current for high power switches and includes a split output stage enabling different slew rates for switching on and off. The DESAT protection and config
    Producent:
    Infineon
    Rozmiar:
    1146 kB
    Stron:
    70
  13. Podgląd PDFa
    Do dokumentacji »

    1ED44171N01B

    25 V single-channel low-side gate driver with integrated fault reporting and enable functionality EiceDRIVER™ 25 V single-channel low-side non-inverting gate driver IC with typical 2.6 A source and sink currents in a tiny 5-lead PG-SOT23 package. It can be used in conjunction with IPMs which integrate a PFC IGBT but no PFC gate driver IC. The logic input is compatible with standard CMOS or LSTTL output. The 1ED44171N01B provides an integrated fault reporting output and adjustable fault clear timer at the u
    Producent:
    Infineon
    Rozmiar:
    1059 kB
    Stron:
    18
  14. Podgląd PDFa
    Do dokumentacji »

    1ED3323MC12N

    8.5 A, 5.7 kV (rms) single-channel isolated gate driver with short-circuit protection and active Miller clamp, UL 1577 & VDE 0884-11 certified EiceDRIVER™ Enhanced single-channel isolated gate driver with +6 A / -8.5 A typical sourcing and sinking peak output current in a DSO-16 wide body package with 8 mm creepage for IGBTs, MOSFETs and SiC MOSFETs. 1ED3323MC12N belongs to the EiceDRIVER™ Enhanced 1ED332x family (F3 family). 1ED3323 offers short-circuit protection (DESAT) for IGBTs and SiC MOSFETs. Th
    Producent:
    Infineon
    Rozmiar:
    1053 kB
    Stron:
    32
  15. Podgląd PDFa
    Do dokumentacji »

    3NP19541ED00

    Zestaw montażowy Siemens 3NP1954-1ED00 1 szt.
    Producent:
    Siemens
    Rozmiar:
    935 kB
    Stron:
    3
  16. Podgląd PDFa
    Do dokumentacji »

    3NP19441ED00

    Zestaw montażowy Siemens 3NP1944-1ED00 1 szt.
    Producent:
    Siemens
    Rozmiar:
    902 kB
    Stron:
    3
  17. Podgląd PDFa
    Do dokumentacji »

    1ED3012MC12I

    5.7 kV (rms) single-channel gate driver IC with reinforced isolation, 6.5 A output current, Opto-emulator input, 12.5 V UVLO EiceDRIVER™ Lite 2300 V single-channel isolated gate driver with 6.5 A sinking and 6 A sourcing peak output current in 6-pin LDSO wide body package for SiC MOSFETs.
    Producent:
    Infineon
    Rozmiar:
    883 kB
    Stron:
    27
  18. Podgląd PDFa
    Do dokumentacji »

    3NP19341ED20

    Zestaw montażowy Siemens 3NP1934-1ED20 1 szt.
    Producent:
    Siemens
    Rozmiar:
    674 kB
    Stron:
    3
  19. Podgląd PDFa
    Do dokumentacji »

    3NP19341ED10

    Zestaw montażowy Siemens 3NP1934-1ED10 1 szt.
    Producent:
    Siemens
    Rozmiar:
    671 kB
    Stron:
    3
  20. Podgląd PDFa
    Do dokumentacji »

    1ED2147S65F

    650 V high-side gate driver IC with over current protection (OCP), multi-function RCIN/Fault/Enable (RFE) and integrated bootstrap diode (BSD) EiceDRIVER™ 650 V high side single channel gate driver IC with a typical 4 A source and 4 A sink current in DSO-8 package for IGBTs, MOSFETs and SiC MOSFETs.
    Producent:
    Infineon
    Rozmiar:
    669 kB
    Stron:
    21
  21. Podgląd PDFa
    Do dokumentacji »

    1ED3330MC12M

    5.7kV (rms) single-channel galvanic isolated gate driver IC with DESAT, active Miller clamp driver, Soft-off, UVLO, and shutdown with fault EiceDRIVER™ Enhanced 5.7 kV single-channel isolated gate driver IC with ±12 A typical sinking and sourcing peak output current in small space-saving DSO-16 fine pitch wide-body package with large creepage distance (>8 mm) ideal for SiC MOSFETs. The gate driver IC also includes integrated protection features such as DESAT protection, active Miller clamp driver, and a
    Producent:
    Infineon
    Rozmiar:
    588 kB
    Stron:
    27
  22. Podgląd PDFa
    Do dokumentacji »

    1EDL8011

    125 V high-side gate driver with single output in DSO-8 package for battery-powered applications The EiceDRIVER™ 1EDL8011 provides fast turn-on/ turn-off of high-side N-channel MOSFETs with its powerful gate current capabilities. For battery-powered applications, 1EDL8011 is used to manage inrush current & protects in case of faults. The driver is available in DSO-8 package including OCP protection feature, adjustable current setting threshold, time delay and a safe start-up mechanism with flexible bla
    Producent:
    Infineon
    Rozmiar:
    541 kB
    Stron:
    26
  23. Podgląd PDFa
    Do dokumentacji »

    3NP19241ED10

    Zestaw montażowy Siemens 3NP1924-1ED10 1 szt.
    Producent:
    Siemens
    Rozmiar:
    463 kB
    Stron:
    3
  24. Podgląd PDFa
    Do dokumentacji »

    1EDP

    Power Line Filter 50Hz/60Hz 1A 250VAC PC Pins Thru-Hole
    Producent:
    TE Connectivity
    Rozmiar:
    172 kB
    Stron:
    3
  25. Podgląd PDFa
    Do dokumentacji »

    1EDK1

    Power Line Filter 50Hz/60Hz 1A 250VAC Quick Connect Panel Mount
    Producent:
    TE Connectivity
    Rozmiar:
    171 kB
    Stron:
    3
