    XDP730-001

    Stackable 30 A, 1.5 mΩ electronic fuse (eFuse) with PMBus® interface for 7 V to 80 V DC rails in a small LIQFN-42 package Infineon's XDP730-001 eFuse integrates a hot-swap controller, a low RDS(on) FET with up to 30 A current carrying capability, and a current sense in a small 7 mm x 7 mm package. With its wide operating voltage range, Surge Immunity, telemetry, and extensive list of protection features against e.g., inrush current, under- and overvoltage, and overcurrent, it is especially suitable for sop
    Producent:
    Infineon
    Rozmiar:
    4927 kB
    Stron:
    83
  2. Podgląd PDFa
    Do dokumentacji »

    XDP720-001

    Stackable 20 A, 3.2 mΩ electronic fuse (eFuse) with PMBus® interface for 7V to 80V DC rails in a small LIQFN-23 package Infineon's XDP720-001 eFuse integrates a hot-swap controller, a low RDS(on) FET with up to 20 A current carrying capability, and a current sense in a small 6 mm x 5 mm package. With its wide operating voltage range, Surge Immunity, telemetry, and extensive list of protection features against e.g., inrush current, under- and overvoltage, and overcurrent, it is especially suitable for sophi
    Producent:
    Infineon
    Rozmiar:
    2962 kB
    Stron:
    85
  3. Podgląd PDFa
    Do dokumentacji »

    XDP711-001

    XDP711-001 is the new member of Infineon's wide input voltage hot-swap controller with programmable digital SOA control ideal for AI servers XDP711-001 is a wide input voltage hot-swap & monitoring controller with digital SOA control & enhancements over XDP710 to meet the high availability & reliability requirements of AI servers while maintaining backward compatibility. It drives single or multiple parallel MOSFETs, enables continuous system health monitoring & high-speed communication via
    Producent:
    Infineon
    Rozmiar:
    2248 kB
    Stron:
    97
  4. Podgląd PDFa
    Do dokumentacji »

    XDP722-001

    Stackable 20 A, 3.2 mΩ electronic fuse (eFuse) for 7V to 80V DC rails in a small LIQFN-23 package Infineon's XDP722-001 eFuse integrates a hot-swap controller, a low RDS(on) FET with up to 20 A current carrying capability, and a current sense in a small 6 mm x 5 mm package. With its wide operating voltage range, and extensive list of protection features against e.g., inrush current, under- and overvoltage, and overcurrent, it is especially suitable for 48 V/54 V (AI) server/data center and fan control appl
    Producent:
    Infineon
    Rozmiar:
    2023 kB
    Stron:
    38
  5. Podgląd PDFa
    Do dokumentacji »

    XDP700-002

    XDP700-002 is industry’s first -48V wide input voltage hot-swap controller with a programmable digital SOA control ideal for Telecom infrastructure XDP700-002 is a new member of Infineon Technologies intelligent hot-swap controller and protection IC family able to drive a single or multiple parallel N-channel MOSFETs. Key resource of XDP700-002 include high-precision AFE, extensive variety of system warnings and protections, high-speed communiction via PMBus to main CPU, reset, shutdown, retry and digital
    Producent:
    Infineon
    Rozmiar:
    2006 kB
    Stron:
    89
  6. Podgląd PDFa
    Do dokumentacji »

    XDP710-002

    XDP710-002 is Infineon's next generation wide input voltage hot-swap controller with programmable digital SOA control ideal for AI servers XDP710-002 Hot-Swap-Controller able to drive a single or multiple parallel N-channel MOSFETs and is backward compatible to XDP710-001 with improved and enahanced features. Key resource of XDP710-002 include high-precision AFE, extensive variety of system warnings and protections, high-speed communiction via PMBus to main CPU, reset, shutdown, retry and digital SOA contr
    Producent:
    Infineon
    Rozmiar:
    1919 kB
    Stron:
    88
  7. Podgląd PDFa
    Do dokumentacji »

    XDP710-001

    XDP™ XDP710 industry’s first wide voltage range hot-swap controller with a programmable digital SOA control for system XDP710-001 is not for new design. Please refer to XDP710-002. XDP710 is the first member of Infineon Technologies intelligent hot-swap controller and protection IC family. This device has a 5.5 V – 80 V input voltage range with transient up to 100 V for 500 ms that drives a single or multiple parallel N-Channel MOSFETs. A combination of high-precision telemetry and digital SOA control bloc
    Producent:
    Infineon
    Rozmiar:
    1849 kB
    Stron:
    85
  8. Podgląd PDFa
    Do dokumentacji »

    XDPP1148-100B

    XDP™ integrated digital controller for DC-DC conversions with PWM and LLC support The XDPP1148-100B is the latest generation of digital controller product family. It adds close-loop LLC topology support, enhanced feed-forward, non-linear fast transient, light load power management and bi-directional configuration. The high-performance AFE, state-machine-based digital control loop, and Cortex®-M0 processor integrated in the 4x4 mm 24-pin VQFN package enables high power quality, low latency, and flexible pow
    Producent:
    Infineon
    Rozmiar:
    1101 kB
    Stron:
    55
  9. Podgląd PDFa
    Do dokumentacji »

    XDPS2221E

    The XDP™ XDPS2221E PWM combines multimode AC-DC PFC and DC-DC hybrid-flyback controllers, ideal for wide output voltage range designs. XDP™ XDPS2221E is a digital combo controller with configurable parameters for protection modes and maximized system performance. The novel ZVS hybrid-flyback (HFB, known also as asymmetrical half-bridge) topology enables ultra-high system efficiency. The integration of PFC and hybrid-flyback into a single package optimizes the system performance by harmonized operation of
    Producent:
    Infineon
    Rozmiar:
    848 kB
    Stron:
    51
  10. Podgląd PDFa
    Do dokumentacji »

    XDPS2201E

    The XDP™ XDPS2201E PWM controller multimode hybrid-flyback controller supporting extra high power density designs The XDP™ XDPS2201E PWM controller is a highly integrated, multimode DC-DC hybrid-flyback (HFB) controller. The controller enables reduction of external parts and optimizes performance. It serves applications with fixed output voltage and offers even more benefits for applications with wide output voltage range.
    Producent:
    Infineon
    Rozmiar:
    722 kB
    Stron:
    41
  11. Podgląd PDFa
    Do dokumentacji »

    XDPE1A2G5B-0000

    Digital dual loop 16-phase controller for applications using AVSBus XDPE1A2G5B digital dual loop 16 phase controller provides power for AI servers, workstations, and telecom applications that use AVSBUS. Typical configurations of 16+0, 15+1, and up to 8+8 are supported. Command and monitoring functions are controlled through the PMBus and AVS interfaces which supports dynamic voltage identification with 1 mV/step, output range up to 3.1 V, offset and trim resolution of 625 uV and accuracy better than 0.5%.
    Producent:
    Infineon
    Rozmiar:
    588 kB
    Stron:
    7
  12. Podgląd PDFa
    Do dokumentacji »

    XDPE1A2G7B-0000

    Digital dual loop 16-phase controller for nVIDIA AI servers and GPU applications XDPE1A2G7B digital dual loop 16 phase controller provides power for nVIDIA AI servers, workstations and high-end desktop GPU applications. Typical configurations of 16+0, 15+1, and up to 8+8 are supported. Command & monitoring functions are controlled through the PMBus and PWMVID interfaces, which supports dynamic voltage identification with 5 mV/step, output range up to 2.75 V, offset and trim resolution of 625 uV and acc
    Producent:
    Infineon
    Rozmiar:
    584 kB
    Stron:
    7
  13. Podgląd PDFa
    Do dokumentacji »

    XDPE192C4C-0000

    Digital dual loop 12-phase controller for Intel VR14 server, workstation, and high-end desktop applications XDPE192C4 can be configured in one of the following phase combinations between the two loops: 12+0, 11+1, 10+2, 8+4 or 6+6 phases. Command and monitoring functions are controlled through the PMBus and SVID interfaces which supports dynamic voltage identification with 5 mV/step or 10 mV/step in Intel mode, output range up to 3.04 V, offset and trim resolution of 625 uV and accuracy better than 0.5%.In
    Producent:
    Infineon
    Rozmiar:
    299 kB
    Stron:
    8
  14. Podgląd PDFa
    Do dokumentacji »

    XDPE19284C-0000

    Digital dual loop 8-phase controller provides power for Intel VR14 server, workstation, and high-end desktop applications XDPE19284 phase configuration is flexible in how the 8 phases are allocated to the 2 loops. Command and monitoring functions are controlled through the PMBus and SVID interfaces which support dynamic voltage identification with 5 mV/step or 10 mV/step in Intel mode, output range up to 3.04 V, offset and trim resolution of 625 uV and accuracy better than 0.5%.Infineon’s multiphase contro
    Producent:
    Infineon
    Rozmiar:
    296 kB
    Stron:
    8
  15. Podgląd PDFa
    Do dokumentacji »

    XDPE132G5H-G000

    XDP™ 16-phase dual loop PWM digital multiphase controller The XDP™ XDPE132G5H is a digital multi-phase buck controller that can be configured in single or dual loop mode and is optimized to support high performance processors that require AVSBus, AMD SVI2, or nVIDIA PWMVID. It supports up to 16 phases that can be flexibly assigned between the two loops. It offers digitally programmable load line thereby eliminating external load line components.
    Producent:
    Infineon
    Rozmiar:
    263 kB
    Stron:
    5
  16. Podgląd PDFa
    Do dokumentacji »

    XDPE19283B-0000

    Digital dual loop 8-phase controller for AMD™ SVI3 server, workstation, and high-end desktop applications XDPE19283B can be configured in one of the following phase combinations between the two loops: 8+0, 7+1, 6+2 and 4+4. Command and monitor functions are controlled through the SVI3 interface which supports dynamic voltage changes, power states, and VR telemetry and status requirements. It utilizes digital technology to implement all control functions, providing the ultimate system solution in terms of f
    Producent:
    Infineon
    Rozmiar:
    247 kB
    Stron:
    8
  17. Podgląd PDFa
    Do dokumentacji »

    XDPE192C3B-0000

    Digital dual loop 12-phase controller for AMD™ SVI3 server, workstation, and high-end desktop applications XDPE192C4 can be configured in one of the following phase combinations between the two loops: 12+0, 11+1, 10+2, 8+4 or 6+6 phases. Command and monitoring functions are controlled through the PMBus and SVID interfaces which supports dynamic voltage identification with 5 mV/step or 10 mV/step in Intel mode, output range up to 3.04 V, offset and trim resolution of 625 uV and accuracy better than 0.5%.Inf
    Producent:
    Infineon
    Rozmiar:
    246 kB
    Stron:
    8
  18. Podgląd PDFa
    Do dokumentacji »

    XDPE12254C-0000

    XDP™ 4+1 phase dual loop digital multiphase controller The XDP™ XDPE12254C is a digital dual rail 4+1 phase controller to power Intel VR13, VR13HC, IMVP8 and IMVP9 server, workstation & high-end desktop applications. It offers flexible phase assignment between the two loops and can be configured as: 4+1, 3+1, ... ,1+1. Digital technology implements all control functions for flexibility and stability. Advanced control loop features enable optimal response to high slew rate load transients.
    Producent:
    Infineon
    Rozmiar:
    242 kB
    Stron:
    5
  19. Podgląd PDFa
    Do dokumentacji »

    XDPE15254D-0000

    XDP™ 5-phase hyper transient phase dual loop multiphase controller The XDP™ XDPE15254D is a hyper transient phase controller. Core voltage is provided by a multiphase buck converter with up to 5 synchronous-rectified channels in parallel, while a second loop provides voltage for the I/O. Any phase can be assigned to either loop, and the phase firing order is fully programmable to offer the ultimate in phase configuration flexibility. Typically, configurations of 5+0, 4+1, 3+2 phases are supported.
    Producent:
    Infineon
    Rozmiar:
    238 kB
    Stron:
    7
  20. Podgląd PDFa
    Do dokumentacji »

    XDPE15284D-0000

    XDP™ 8-phase hyper transient phase dual loop multiphase controller The XDP™ XDPE15254D is a hyper transient phase controller. Core voltage is provided by a multiphase buck converter with up to 8 synchronous-rectified channels in parallel, while a second loop provides voltage for the I/O. Any phase can be assigned to either loop, and the phase firing order is fully programmable to offer the ultimate in phase configuration flexibility. Typically, configurations of 8+0, 7+1, 6+2, 5+3, or 4+4 phases are suppor
    Producent:
    Infineon
    Rozmiar:
    231 kB
    Stron:
    7
  21. Podgląd PDFa
    Do dokumentacji »

    XDPE152C4D-0000

    XDP™ 12-phase hyper transient phase dual loop multiphase controller The XDP™ XDPE15254D is a hyper transient phase controller. Core voltage is provided by a multiphase buck converter with up to 12 synchronous-rectified channels in parallel, while a second loop provides voltage for the I/O. Any phase can be assigned to either loop, and the phase firing order is fully programmable to offer the ultimate in phase configuration flexibility.
    Producent:
    Infineon
    Rozmiar:
    228 kB
    Stron:
    7
  22. Podgląd PDFa
    Do dokumentacji »

    XDPE14283A-0000

    XDP™ 8-phase dual loop digital multiphase controller The XDP™ XDPE14283A is a digital dual rail 8-phase controller that provides power for AMD SVI2 server, workstation & high-end desktop applications. The controller offers flexible phase assignment between the two loops: 8+0, 7+1, 6+2, ..., 4+4. Digital technology implements all control functions for flexibility and stability. Advanced control loop features enable optimal response to high slew rate load transients.
    Producent:
    Infineon
    Rozmiar:
    213 kB
    Stron:
    5
  23. Podgląd PDFa
    Do dokumentacji »

    XDPE14284A-0000

    XDP™ 8-phase dual loop digital multiphase controller The XDP™ XDPE14284A is a digital dual rail 8-phase controller to power for Intel VR13, VR13HC, VR14 and IMVP9 server, workstation & high-end desktop applications. The controller offers flexible phase assignment between the two loops: 8+0, 7+1, 6+2, ... ,4+4. Digital technology implements all control functions for flexibility and stability. Advanced control loop features, enable optimal response to high slew rate load transients.
    Producent:
    Infineon
    Rozmiar:
    213 kB
    Stron:
    5
  24. Podgląd PDFa
    Do dokumentacji »

    XDPE12284C-0000

    XDP™ 8-phase dual loop digital multiphase controller The XDP™ XDPE12284C is a digital dual-rail 8-phase controller to power for Intel VR13, VR13HC, IMVP8 and IMVP9 server, workstation & high-end desktop applications. It offers flexible phase assignment between the two loops: 8+0, 7+1, ... ,4+4. Digital technology implements all control functions for flexibility & stability. Advanced control loop features enable optimal response to high slew rate load transients.
    Producent:
    Infineon
    Rozmiar:
    201 kB
    Stron:
    5
