  1. Podgląd PDFa
    Do dokumentacji »

    PM CPP-45 10SX-19 2MIDORI

    Rezystancja 2 kohm lin 0,5%; gear potentiometer 10:1; 3 term inals, in corner direction of the shaft output 6mm/18mm dim. 61x50(68)x38mm (podobny pot.z zestawu CPP-45 z RS 4mmx16mm ) Proponujemy zamiennik -następca CPP-45 10-SX-28 lub SC
    Producent:
    Meditronik
    Rozmiar:
    1203 kB
    Stron:
    1
  2. Podgląd PDFa
    Do dokumentacji »

    PM CPP-45 10SX-SC MIDORI

    Rezystancja 2 kohm Lin 0,3%; potentiometer; gear ratio 10:1 with screwterminal; shaft 6mm x 16mm; PH 11mm fi 2mm; 4 x M3 na fi 22mm; Dimensions 61x70x38 mm; Tol.+-10%; Lin +-0,3% ( podobny potencjometr z zestawu cpp-45sb) następca: PM CPP-45 10SX-SC-1 PM CP-45F-10SX-SC MIDORI następca potencjometru CPP-45 10SX-SC 2K MIDORI
    Producent:
    Meditronik
    Rozmiar:
    410 kB
    Stron:
    1
  3. Podgląd PDFa
    Do dokumentacji »

    1708Z03-096.018

    PW70A Precision Potentiometer in cast iron case to IP40. Potentiometer is 8.57k Ohms +-1% across the 60 Degree movement, without gears and includes a slipping clutch for mechanical protection. 125mm x 75mm x 60mm overall. Shaft is 6mm x 16mm Fixing flange has 4 x 6mm dia smooth holes on 88mm pcd. Used on FAS Packaging Machinery and any high performace dancer bar or dancing roller applications. Other resistance values are available on request. Customs Tariff code: 85 33 31 000 Potencjometr 1700Z04-096.038 Pa
    Producent:
    Meditronik
    Rozmiar:
    392 kB
    Stron:
    1
  4. Podgląd PDFa
    Do dokumentacji »

    9FG1901

    DB1900G Frequency Gearing Clock for Intel CPU, PCIe Gen1 & Fully Buffered DIMM Clocks
    Producent:
    Renesas Electronics
    Rozmiar:
    392 kB
    Stron:
    18
  5. Podgląd PDFa
    Do dokumentacji »

    9FG1904-1

    DB1900GS-Derative Frequency Gearing Clock for Intel CPU, PCIe Gen2 & Fully Buffered DIMM Clocks
    Producent:
    Renesas Electronics
    Rozmiar:
    383 kB
    Stron:
    23
  6. Podgląd PDFa
    Do dokumentacji »

    9FG1201

    DB1200G Frequency Gearing Clock for Intel CPU, PCIe Gen1 & Fully Buffered DIMM Clocks
    Producent:
    Renesas Electronics
    Rozmiar:
    355 kB
    Stron:
    24
  7. Podgląd PDFa
    Do dokumentacji »

    9FG1200-1

    DB1200GS Frequency Gearing Clock
    Producent:
    Renesas Electronics
    Rozmiar:
    314 kB
    Stron:
    24
  8. Podgląd PDFa
    Do dokumentacji »

    1708Z03-065.011

    Potentiometer in Cast Iron IP40 Case - 90 degree Gear-less movement x 2571 Ohms 1708Z03-065.011 + 1700Z04-065.117 (PW70dA with PW 1700Z04-065.117) PW70dA Precision Potentiometer in cast iron case to IP40. Potentiometer is 2571 Ohms +-1% across the 90 Degree movement, with aditional 270 degree movement. 125mm x 75mm x 60mm overall. Shaft is 6mm x 16mm Fixing flange has 4 x 6mm dia smooth holes on 88mm pcd. Manufacturer is FSG Full part number is 1708Z03-065.011 as PW70dA with PW 1700Z04-065.117
    Producent:
    Meditronik
    Rozmiar:
    279 kB
    Stron:
    1
  9. Podgląd PDFa
    Do dokumentacji »

    PM CP-45F-10SX-SC

    Rezystancja 2 kohm Lin 0,3%; potentiometer; gear ratio 10:1 with screwterminal; shaft 6mm x 16mm; PH 11mm fi 2mm; 4 x M3 na fi 22mm; Dimensions 61x70x38 mm; Tol.+-10%; Lin +-0,3% ( podobny potencjometr z zestawu CP-45F ) następca: PM CPP-45 10SX-SC-1 PM CP-45F-10SX-SC MIDORI następca potencjometru CPP-45 10SX-SC 2K MIDORI
    Producent:
    Meditronik
    Rozmiar:
    188 kB
    Stron:
    2
  10. Podgląd PDFa
    Do dokumentacji »

    3601Z02-001.006

    Precision Potentiometer PW620-29/90/120MIId-G90 in cast casing with cable inlet for moist atmospheres IP code IP65 Intermediate gearbox, backlash reduced 2 separate windings at separate formers wiper continuous rotation without limit stops. Winding I/II: according to circuit 702 3 tappings with 120° offset 2 wipers with 180° offset resistance approx. 2087 U Ý of driving shaft 6mm Weight: 0,800 KG Manufacturers part number is PW620MIId-G90 (3601Z02-001.006) Customs Tariff code: 85 33 31 000
    Producent:
    Meditronik
    Rozmiar:
    151 kB
    Stron:
    1
  11. Podgląd PDFa
    Do dokumentacji »

    MPH22Q12-22HPM-10N

    Motor with 24V DC gear No 12 ( ratio 1:3101 ) 100 ohm / 50 kohm +-5%
    Producent:
    Meditronik
    Rozmiar:
    106 kB
    Stron:
    1
  12. Podgląd PDFa
    Do dokumentacji »

    PM CPP-45 10SX PORÓWNANIE

    Porównanie modeli podobnych Potencjometr z przekładnią 10:1 Rezystancja 2 kohm, lin 0,5% Delin Gear, 3 terminals, in corner direction of the shaft ou tput shaft 6mm/18mm dimension 61x50(68)x38mm
    Producent:
    Meditronik
    Rozmiar:
    83 kB
    Stron:
    1
